REFERENCE ARCHITECTURE — NOT IN ACTIVE DEVELOPMENT
BUCKET
34 m³
ATLAS TRAY MATCH
4 passes
BREAKOUT FORCE
2.4 MN
OPERATION
24 / 7
CREW ONBOARD
0
INORE ENGINEERINGDWG T-301 · REV C
TITLE
TALON, SIDE ELEVATION
DWG NO
T-301
REV
C
SCALE
1:200
SHEET
1 / 1
STATUS
FUTURE PROGRAM
DATE
2026-06-14
UNITS
M
PROJECTION
THIRD ANGLE
DRAWN
INORE ENG.
At the face
01 / PASS SYNC
Loading is scheduled against the ATLAS convoy, not the other way around. No truck idles at the face; no bucket swings over an empty bay.
02 / DIG TO GRADE
Every bucket follows the live grade map built from site survey data, ore and waste split at the face, not at the mill.
03 / UNDER THE HIGHWALL
TALON works the benches no crew should stand under. Wall-monitoring radar feeds its stop envelope; rockfall is a maintenance event, not a casualty.
Learn more about TALON
TALON is a reference architecture for an autonomous loading system. Get in touch to discuss the concept.
